Revised Local Reference (RLR) Diagram for JOLO, SULU

Station ID: 260

RLR diagram based on the information in the datum section below

If the image above appears blurry, or you would like to see a larger image, please view the full-sized image of the RLR diagram.

Datum information

Add 5.040m to data values 1947 onwards to refer to RLR
RLR is 9.300m below primary benchmark BM 1
